Content Source: 2019 GEM em1400 LSV Owner’s Manual (9929177 R02) > Safety Chapter
IMPORTANT |
The Owner's Manual for this vehicle contains warnings, instructions and other information you must read and fully understand before safely riding or performing maintenance on this vehicle.Always follow the warnings and instructions in Owner's Manual. Click the CONTENTS link above for the Table Of Contents, or download a full PDF of the Owner Manual in the Owner Support area of Polaris.com |
WARNING
eM1400 LSV |
BASE |
BASE WITH SIDES |
BASE WITH VAN ENCLOSURE |
---|---|---|---|
TIRE PRESSURE IN PSI (KPa) |
FRONT 35 (241) REAR 35 (241) |
FRONT 35 (241) REAR 35 (241) |
FRONT 35 (241) REAR 35 (241) |
VEHICLE OPERATING WEIGHT |
1703 lbs. (772 kg) |
1758 lbs. (797 kg) |
1828 lbs. (829 kg) |
MAXIMUM CARGO PAYLOAD |
900 lbs. (408 kg) |
845 lbs. (383 kg) |
775 lbs. (351 kg) |
GVW = VEHICLE + OCCUPANTS + PAYLOAD + ACCESSORIES |
2953 lbs. (1339 kg) |
2953 lbs. (1339 kg) |
2953 lbs. (1339 kg) |
Read Operation and Maintenance Manual for more detailed loading information. |
